In-line non-return valve made of stainless steel (Aisi 304),
spring-loaded and flow control disc with seal ring in EPDM with WRAS approval
for drinking water. Connection
male threaded suction side and female threaded delivery side according
to UNI ISO 228/1.
The IDRJA/MFA check valve, available in sizes from 1" up to 2", is generally used in civil and
industrial hydraulic systems in the outlet position where it is
necessary to avoid fluid return and works at a nominal working pressure
(PN) of 16 bar.
Brand
MONDEO
Material
Aisi 304
Seal
EPDM
DN
25 - 50
PN
16
Approvals
WRAS + NSF/ANSI/CAN 61 & 372
