KIT 04 N

Fixed calibration pressure flow switch. Body, upper part and gland made of polypropylene, internal diaphragm made of EPDM, stainless steel screws (stainless steel AISI 304). In-line suction and delivery connections 1" male. Equipped with electronic automatic start and stop device to prevent the pump from running dry, manual reset button. Reset pressure of 1.5 and 2.2 Bar depending on model. Generally, the Pressdrive 04 pressure switch is used to control the operation of a pump by ensuring a constant pressure in the system. Ideal for pressurising small buildings and irrigation systems. 10 A electronic card for electric pumps up to 1.5 HP. Made in Italy, CE and TUV certified.

Key Features

Brand ESPA
Restart pressure 1.5 - 2.2 bar fixed
Voltage 1 x 230V
Max. pump power 1.1 kW
